DESCRIPTION

Overview

Basic Info.

Model NO.	cable249
Range of Application	Flame Retardant
Certification	ISO9001, CE, CCC, RoHS, VDE
Sample	Free Samples Available
Temperature	-40 ºC~60 ºC
Annual Capacity	300,000kms
Standard	UL83/UL1569/UL1685
Size Scope	14AWG-750mcm
Product Name	Thwn Thhn Insulated Grounding Conductor Mc Cable
Model Number	1/0 2/0 3/0 4/0 Thhn/Thwn Conductors
Keyword	Mc Cable with UL
Delivery Time for Mass Production	3-15 Working Days
Delivery Time for Samples	1-3 Working Days
Warranty Time	15 Years at Least with Proper Use
Appliance	House Wiring,Internal Wiring,Equipment etc.
OEM	Yes
Model No	Mc Metal Clad Cable
Transport Package	as Per Requested
Specification	Roll
Trademark	Qianwang
Origin	Shandong, China
HS Code	8544200000
Production Capacity	2000000rolls/Year

Product Description

Products Details

Production Description

1000 ft. 12-Gauge/3-Gauge Solid CU MC (Metal Clad) Type cable THHN/THWN conductors rated 90 degree C dry

Cable Construction
Type MC Cable is constructed with soft-drawn copper, Type THHN/THWN conductors rated 90°C dry available in sizes 14 AWG through 2 AWG, and a green insulated grounding conductor. The conductors are cabled together and a binder tape bearing the print legend is wrapped around the assembly. Aluminum interlocking armor is applied over the assembly.

Standard:

ASTM-B,B-801 and B-836

UL standard 44 for XHHW-2

UL Standard 1569

RoHS environmental conductive requirement

JACKET COLOUR CODE - Typical Application Guide•WHITE - General Residential Wiring•RED - 2 Black and Red conductors - 208V-240V Circuits (no neutral)•ORANGE - No. 10 AWG General Residential Wiring•YELLOW - No. 12 AWG General Residential Wiring•BLUE - No. 14 AWG - 2 black and white conductors - 120V Arc Fault Circuit Interupter Applications
Specification.

Size (AWG)	Strands No./OD (mm²)	Insulation Thickness (mm)		Approx. O.D. mm	Max.DC Resistance (20ºC Ω/km) Bare Copper	Approx. Weight (kg/km)
		PVC	Nylon
14/2+14/1	1/1.63	0.38	0.10	11.9	8.45	141.54
14/3+14/1	1/1.63	0.38	0.10	12.5	8.45	170.75
14/4+14/1	1/1.63	0.38	0.10	13.1	8.45	200.36
12/2+12/1	1/2.05	0.38	0.10	12.8	5.31	184.82
12/3+12/1	1/2.05	0.38	0.10	13.6	5.31	227.02
12/4+12/1	1/2.05	0.38	0.10	14.4	5.31	269.69
10/2+10/1	1/2.59	0.51	0.10	14.5	3.343	263.46
10/3+10/1	1/2.59	0.51	0.10	15.5	3.343	329.09
10/4+10/1	1/2.59	0.51	0.10	16.6	3.343	395.30
8/2+10/1	7/1.23 1/2.59	0.76/0.51	0.13/0.10	17.1	2.144/ 3.343	364.61
8/3+10/1	7/1.23 1/2.59	0.76/0.51	0.13/0.10	18.6	2.144/ 3.343	471.96
8/4+10/1	7/1.23 1/2.59	0.76/0.51	0.13/0.10	20.2	2.144/ 3.343	582.33
6/2+8/1	7/1.56 7/1.23	0.76/0.76	0.13/0.13	21.3	1.348/ 2.144	521.37
6/3+8/1	7/1.56 7/1.23	0.76/0.76	0.13/0.13	22.0	1.348/ 2.144	686.69
6/4+8/1	7/1.56 7/1.23	0.76/0.76	0.13/0.13	23.9	1.348/ 2.144	850.00
4/2+8/1	7/1.96 7/1.23	1.02/0.76	0.15/0.13	24.1	0.8481/ 2.144	721.34
4/3+8/1	7/1.96 7/1.23	1.02/0.76	0.15/0.13	27.3	0.8481/ 2.144	1023.89
4/4+8/1	7/1.96 7/1.23	1.02/0.76	0.15/0.13	28.7	0.8481/ 2.144	1284.51
3/2+6/1	7/2.20 7/1.56	1.02/0.76	0.15/0.13	25.7	0.6727/ 1.348	944.59
3/3+6/1	7/2.20 7/1.56	1.02/0.76	0.15/0.13	28.0	0.6727/ 1.348	1258.36
3/4+6/1	7/2.20 7/1.56	1.02/0.76	0.15/0.13	30.6	0.6727/ 1.348	1575.69
2/2+6/1	7/2.47 7/1.56	1.02/0.76	0.15/0.13	27.4	0.5335/ 1.348	1097.85
2/3+6/1	7/2.47 7/1.56	1.02/0.76	0.15/0.13	30.0	0.5335/ 1.348	1478.98
2/4+6/1	7/2.47 7/1.56	1.02/0.76	0.15/0.13	32.8	0.5335/ 1.348	1867.82
1/2+6/1	19/1.69 7/1.56	1.27/0.76	0.18/0.13	30.9	0.4230/ 1.348	1334.92
1/3+6/1	19/1.69 7/1.56	1.27/0.76	0.18/0.13	33.9	0.4230/ 1.348	1816.76
1/4+6/1	19/1.69 7/1.56	1.27/0.76	0.18/0.13	37.2	0.4230/ 1.348	2314.28

Detailed Photos

Certifications



Production
Laboratory

Trade show-Exhibition
FAQ

1. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
2.What can you buy from us?
Wires,Cables ,Cable Assemblies,Cable Trays&Condiut pipe.
3.Can I get a free sample?
Sure,we offer free sample,you only pay the freight.

4.Payment

Our payment term is usually T/T 30% in advanced, the balance before picking up the goods.L/C,PayPal,Western Union are also acceptable.
